Converter primary dust removal fan

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Specification


Product Name

Typical performance parameters

Conveying medium


Structural type


Features

Wet primary dust removal fan





Flow range:12000~40000m³/min
design pressure:17000~18500Pa

Operating temperature:130~150℃

Converter gas

Double support centrifugal

Backward blades,
high efficiency and energy saving,
the impeller is made of high-strength
steel wear-resistant material,
and the horizontal opening structure
allows the rotor to be lifted out for maintenance
without moving the fan inlet and outlet connectors.

Dry primary dust removal fan

Flow range:

2500m³/min

design pressure:7300Pa

Operating temperature:160℃,
Temperature up to:200℃

Converter gas

Double support axial flow

The fan is composed of an air inlet chamber,
front guide vanes, impellers, rear guide
vanes and other components.
The fan impeller is made of
high-strength wear-resistant material,
and the blades are treated with
wear-resistant treatment to extend the
overall service life of the fan.
