7-07D High Pressure Centrifugal Fan

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Overview
7-07 high pressure centrifugal fan, outputting very high pressure, can transport various kinds of gas at normal temperature or high temperature and all kinds of materials, and can be used in poor working conditions, such as: conveying high temperature/hazardous/dangerous gas, conveying pulverized coal, conveying hard granules/powder/particles/fibers, forced ventilation, industrial duct collector, air filtration system, flue gas desulfurization, flue gas denitration, industrial boiler blowing air and inducing air, all kinds of rotary kiln/calcining kiln of materials conveying, smelting furnace and foundry furnace, combustion of blast furnace, blast furnace coal injection, coal gas boosting and conveying, etc.
Features
1. Can output higher discharge pressure, and working at high medium temperature condition, applicable to any industry condition which need to conveying high pressure & high temperature gas.
2. Compact structure, save installation space.
3. In the case of using system base, so easy for installation, no need of professionals’ direction.
4. Adopting high quality carbon steel manufacturing, or stainless steel and other metal materials according to customers’ requirements.
5. Can satisfy different dust loading conditions that low dust loading to a good deal dust loading, the surface hardness of impeller can reach to HRC60~70 after special processing, greatly extending impeller’s service life.
6. Fitting tightly of parts, good sealing, ensuring no reducing of output pressure.
7. The welding line of impeller and main shaft passed ultrasonic flaw detection, ensuring no defect of welding and materials, guarantee strength.
8. Impeller passed high standard dynamic balancing, ensuring stable running of fan.
Specifications

Application

Temperature

Normal temperature air

Hot air

Air composition

Clean air

Dusty air

Corrosive gas

Combustible gas

Powder materials

Light particle materials

Performance

Impeller diameter

500-3000

mm

Speed of main shaft

≤4000

rpm

Pressure range

451-27519

Pa

Flow range

173-100788

m3/h

Structure

Blade

Backward

Impeller support

SWSI (Single Width, Single Inlet), Impeller overhung.

Drivetrain

V-belt drivetrain

Can assign

Lubrication

Oil bath lubrication

Can assign

Bearing cooling

Air cooling or Circulating Water cooling

System
configuration

Motor

SIEMENS, ABB, SIMO, LA…

Can assign

Impeller

Carbon steel

Impeller cone (Air Inlet)

Carbon steel

Case

Carbon steel

Air damper

Carbon steel

Main shaft

High-strength carbon structural steel

Bearing

FAG, SKF, ZWZ, C&U…

Bearing housing

Cast iron



Drivetrain

V-belt

Can assign

Foundation bolt

Carbon steel



Optional
components

System base frame, Protective screening,
Silencer, Inlet & Outlet pipeline compensator,
Inlet & Outlet flange, Electric actuator,
Motor rain cover, Temperature sensor, Vibrating sensor,
Soft starter, Inverter, Special Electrical Motor,
System monitoring Instrument, Lube system, Overhead lube tank.
