6-11F High Pressure Blowers & Fans

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Overview

6-11 high pressure heavy centrifugal fan, with excellent performance, can convey incombustible gas at normal temperature or high temperature and Particle materials/ Powder materials/ Fragment materials/ Fiber materials. It is commonly used in large dust collector system, industrial waste gas desulfurization or denitration, large industrial boiler system, large industrial rotary kiln/ calcining kiln system, mineral powder sintering (sintering) and other large industrial system.

Features

1. Can output high discharge pressure, applicable to any industry condition where needing to conveying high pressure & normal air.
2. Customizing design according to customer’s performance requirements, and optimizing by CFD technology, energy consumption lower than same fans.
3. Regarding to material of impeller and main shaft, we will choose high strength carbon steel, low alloyed steel, high temperature resistant alloy steel, high temperature resistant high strength alloy steel according to different medium temperature and running speed, ensuring the impeller and main shaft keeping reliable strength in high temperature.
4. Can satisfy different dust loading conditions that low dust loading to a good deal dust loading, the surface hardness of impeller can reach to HRC60~70 after special processing, greatly extending impeller’s service life.
5. Fitting tightly of parts, good sealing, ensuring no reducing of output pressure.
6. Impeller of annealing treatment, completely eliminating structure of internal stress when welding, ensuring impeller appearance won’t occur creepage and flaw.
7. The welding line of impeller and main shaft passed ultrasonic flaw detection, ensuring no defect of welding and materials, guarantee strength.
8. Impeller passed high standard dynamic balancing, ensuring stable running of fan.
9. Trial assembly after finishing production, ensuring no interference between components.
10. Provide on site arrangement service.

Specifications

Application	Temperature	Normal temperature air
		Hot air
	Air composition	Clean air
		Dusty air
		Powder materials
		Light particle materials
Performance	Impeller diameter	1500-3600	mm
	Speed of main shaft	≤1450	rpm
	Pressure range	2304-14068	Pa
	Flow range	52395-575176	m3/h
Structure	Blade	Backward
	Impeller support	SWSI (Single Width, Single Inlet), Bearing housing is self-supporting. One bearing on each side supported by independent pedestals.
	Drivetrain	Coupling drivetrain	Can assign
	Lubrication	Oil bath lubrication	Can assign
	Bearing cooling	Circulating Water cooling
		Circulation Oil cooling
System configuration	Motor	SIEMENS, ABB, SIMO, LA…	Can assign
	Impeller	Carbon steel
	Impeller cone (Air Inlet)	Carbon steel
	Case	Carbon steel
	Air damper	Carbon steel
	Main shaft	High-strength carbon structural steel
	Bearing	FAG, SKF, ZWZ, C&U…
	Bearing housing	Cast iron
	Drivetrain	Coupling	Can assign
	Foundation bolt	Carbon steel
Optional components	System base frame, Protective screening, Silencer, Inlet & Outlet pipeline compensator,Inlet & Outlet flange, Damper, Electric actuator, Shock isolator, Diaphragm coupling, Fluid coupling, Motor rain cover, Temperature sensor, Vibrating sensor, Soft starter, Inverter, Special Electrical Motor,System monitoring Instrument, Lube system, Overhead lube tank.
