Application |
Temperature |
Normal temperature air |
|
Hot air |
|||
Air composition |
Clean air |
||
Dusty air |
|||
Corrosive gas |
|||
Powder materials |
|||
Light particle materials |
|||
Performance |
Impeller diameter |
1500-3500 |
mm |
Speed of main shaft |
≤1450 |
rpm |
|
Pressure range |
4217-15694 |
Pa |
|
Flow range |
4293-773605 |
m3/h |
|
Structure |
Blade |
Backward |
|
Impeller support |
SWSI (Single Width, Single Inlet), Impeller overhung. |
||
Drivetrain |
Coupling drivetrain |
Can assign |
|
Lubrication |
Oil bath lubrication |
Can assign |
|
Bearing cooling |
Circulating Water cooling |
||
Circulation Oil cooling |
|||
System |
Motor |
SIEMENS, ABB, SIMO, LA… |
Can assign |
Impeller |
Carbon steel |
||
Impeller cone (Air Inlet) |
Carbon steel |
||
Case |
Carbon steel |
||
Air damper |
Carbon steel |
||
Main shaft |
High-strength carbon structural steel |
||
Bearing |
FAG, SKF, ZWZ, C&U… |
||
Bearing housing |
Cast iron |
|
|
Drivetrain |
Coupling |
Can assign |
|
Foundation bolt |
Carbon steel |
|
|
Optional |
System base frame, Protective screening, |
