Cement ertical mill seal fan

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Overview
Cement vertical mill seal fan, is exclusively used in cement vertical mill system protection. It output high pressure, the front of the filter filtering effect is good, to ensure the sealing requirements of cement vertical mill.
Features
1. Can output high discharge pressure
2. The front of the fan connection with multi-channel, large flow rate of air filter, filtering effect is good, does not affect the fan performance
3. Air filters filter bag service life is long, can be replaced
4. Small volume, compact structure, can be installed in narrow space.
5. Easy for installation, don’t need professionals to direct.
6. The motor load can be automatically reduced when airflow resistance increasing, to prevent motor from destroying
7. Fitting tightly of parts, good sealing, ensuring no reducing of output pressure.
8. Impeller passed high standard dynamic balancing, ensuring stable running of fan.
9. Running test and vibration value test for fans after finishing manufacturing, ensuring running reliably.
Specifications

Application

Temperature

Normal temperature Air

Air composition

Clean air

Performance

Impeller diameter

400-1000

mm

Speed of mainshaft

≤4000

rpm

Pressure range

10885-10728

Pa

Flow range

768-2919

m3/h

Structure

Blade

Forward

Impeller Support

SWSI (Single Width, Single Inlet), Impeller overhung.

Drivetrain

Direct drivetrain

Can assign

System
configuration

Motor

SIEMENS, ABB, SIMO, LA…

Can assign

Impeller

Carbon steel

Impeller cone (Air Inlet)

Carbon steel

Case

Carbon steel

Foundation bolt

Carbon steel



Optional
components

Outlet pipeline compensator,

Outlet flange, Motor rain cover, Special Electrical Motor
