Textile axial flow fan FZ40

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Overview

The textile axial flow fan is exclusively used in ventilating of textile factory.

Features

1. Impeller passed high standard dynamic balancing, ensuring stable running of fan.
2. Running test and vibration value test for fans are done after finishing manufacturing, ensuring reliable running
3. With Small starting current, don’t need motor soft start device for below 7.5kw power.
4. V belt transmission can make your fan to run under the most appropriate speed
5. Very good anti-corrosion performance, which expands the application of this fan is textile factory for ventilation in the textile and printing workshops .

Specifications

Application	Temperature	Normal temperature air
Application	Air composition	Clean air
Performance	Impeller diameter	400-2200	mm
	Speed of main shaft	≤1450	rpm
	Pressure range	251-170	Pa
	Flow range	45313-70325	m3/h
Structure	Impeller support	Motor on Integral Base For belt drive. Two bearings on internal supports. Motor on casing or on integral base. Drive through belt fairing.
	Drivetrain	V-belt drivetrain	Can assign
	Lubrication	Oil bath lubrication	Can assign
	Bearing cooling	Air cooling
System configuration	Motor	SIEMENS, ABB, SIMO, LA…	Can assign
	Impeller	Carbon steel
	Case	Carbon steel
	Main shaft	High-strength carbon structural steel
	Bearing	FAG, SKF, ZWZ, C&U…
	Bearing housing	Cast iron
	Drivetrain	V-belt	Can assign
	Foundation bolt	Carbon steel
Optional components	Protective screening, Motor rain cover, Temperature sensor, Vibrating sensor, Soft starter, Inverter, Special Electrical Motor, System monitoring Instrument.
